Find Your Ideal Vacuum Furnace
View more
Send Email
Configurable
Technical Parameters
Tailor the furnace configuration to meet your specific process requirements, including size, vacuum level, heating elements, and atmosphere control
-
Chamber size
-
Vacuum level
-
Heating elements
-
Atmosphere control
Size
Type
Options
Materials
Atmospheres
Method
Chamber Size
| Minimum | Highest |
|---|---|
| 100 × 100 × 100 mm | 800 × 800 × 3000 mm |
Vacuum System Type
- Rotary Pump (up to 10 Pa)
- Roots Pump (500 Pa – 0.1 Pa)
- Diffusion Pump (10 – 0.006 Pa)
- Turbomolecular Pump (≤ 0.006 Pa)
Heating Element Options
- Resistance Wire (up to 1200°C)
- SiC Elements (1600–1800°C)
- MoSi₂ Heaters (up to 1400°C)
- Graphite (up to 2200–2300°C)
- Molybdenum (up to 1600°C)
- Tungsten (up to 2500°C)
Hot Zone Materials
- Heat-Resistant Steel
- Graphite
- Ceramic Fiber (Al₂O₃)
- Tungsten
- Molybdenum Foil
- Induction Melting Coil (Copper)
Available Atmospheres
Loading Method
- Front Loading
- Bottom Loading
- Top Loading
- Automatic Loading
Typical Applications
Frequently
Asked Questions
What materials can the vacuum furnace process ?
metals (including stainless steel, titanium alloys, copper alloys, and nickel-based alloys), ceramics, new materials, carbides, powder metallurgy materials, gemstones, etc.
What is the maximum processing temperature ?
Depending on the furnace type, the maximum temperature can reach 2200°C (for example, molybdenum furnaces and graphite furnaces can reach the high-temperature range).
What should I do if I am not sure what heat treatment process my material requires?
We provide sample testing and process support. Our engineers will provide a complete solution based on the material and process requirements.
Do you have relevant certificates ?
The equipment complies with CE / ISO / electrical safety standards.
What after-sales support is available?
We provide fast-response after-sales service, including remote support, sample testing, and process solution development, ensuring customers can successfully complete heat treatment production.
Can the equipment be customized ?
Customization is available for size, temperature, atmosphere, and automation.
From Design to Delivery —
One-Stop Furnace Solutions
- Submit your requirements; customize furnace size, temperature, and atmosphere based on materials
- Provide a practical, executable technical solution
- Production after solution confirmation
- For standard models in stock, immediate shipment is available
- Strict testing to ensure temperature, vacuum, and control performance meet specifications
- On-site installation or installation guidance
- Operator training and fast after-sales support
- Standard warranty and long-term spare parts supply
